Study case ratio gear of stepper motor on electronic throttle using PID control

Ayu Sandra Dewi, Universitas Negeri Yogyakarta, Indonesia
Zainal Arifin, Universitas Negeri Yogyakarta, Indonesia
I Wayan Adiyasa, Universitas Negeri Yogyakarta, Indonesia


The throttle is a component that determines the amount of airflow into the combustion chamber. The latest in-vehicle technology makes it possible to adjust the fly valve electronically. The electronic system adjusts the angle size by comparing the predetermined setpoints. In research, electronic system designs are based on existing models. The throttle model uses a stepper motor drive. Electronic control using a microcontroller with proportional-integral-derivative (PID) control. While the setpoint is based on a reference from the throttle position sensor (TPS) sensor. The greater the throttle reference value, the greater the angle opening of the butterfly valve. The results of this study obtained a simulation model of electronic throttle control from gear ratios of 1: 1, 5: 1, and 10: 1 for conventional vehicles.

Full Text:



L. Gevorkov, V. Šmídl, and M. Sirový, “Stepper Motor Based Model of Electric Drive for Throttle Valve,” Ann. DAAAM Proc. Int. DAAAM Symp., vol. 29, no. 1, pp. 1102–1107, 2018.

R. P. Ruilope, “Modelling and Control of Stepper Motors for High Accuracy Positioning Systems Used in Radioactive Environments,” Universidad Polit´ecnica de Madrid, 2014.

M. Reichhartinger and M. Horn, “Application of Higher Order Sliding-mode Concepts to a Throttle Actuator for Gasoline Engines,” IEEE Trans. Ind. Electron., vol. 56, no. 9, pp. 3322–3329, 2009.

X. Yuan, Y. Wang, and L. Wu, “SVM-based Approximate Model Control for Electronic Throttle Valve,” IEEE Trans. Veh. Technol., vol. 57, no. 5, pp. 2747–2756, 2008.

P. V. Kasab, N. B. Chopade, and S. Bhagat, “Implementation of Throttle Position Sensor for Angular Movement in Automobiles,” Proc. - 2019 5th Int. Conf. Comput. Commun. Control Autom. ICCUBEA 2019, pp. 2–5, 2019.

K. Song and S. Li, “Thermodynamic Characteristics Analysis of a High Temperature Fuel Flow-rate Control Valve,” ISSCAA2010 - 3rd Int. Symp. Syst. Control Aeronaut. Astronaut., vol. 53, no. 3, pp. 1333–1338, 2010.

J. Gao, K. Feng, Y. Wang, Y. Wu, and H. Chen, “Design, Implementation and Experimental Verification of A Compensator-Based Triple-Step Model Reference Controller For An Automotive Electronic Throttle,” Control Eng. Pract., vol. 100, no. April, p. 104447, 2020.

X. Jiao, J. Zhang, and T. Shen, “An Adaptive Servo Control Strategy for Automotive Electronic Throttle and Experimental Validation,” IEEE Trans. Ind. Electron., vol. 61, no. 11, pp. 6275–6284, 2014.

B. Ashok, S. Denis Ashok, and C. Ramesh Kumar, “Trends and Future Perspectives of Electronic Throttle Control System in a Spark Ignition Engine,” Annu. Rev. Control, vol. 44, pp. 97–115, 2017.

Y. Pan, Ü. Özguner, and O. H. Daǧci, “Variable-Structure Control of Electronic Throttle Valve,” IEEE Trans. Ind. Electron., vol. 55, no. 11, pp. 3899–3907, 2008.

X. Jiao and T. Shen, PID Control with Adaptive Feedback Compensation for Electronic Throttle, vol. 45, no. 30. IFAC, 2012.

Y. Li, B. Yang, T. Zheng, Y. Li, M. Cui, and S. Peeta, “Extended-State-Observer-Based Double-Loop Integral Sliding-Mode Control of Electronic Throttle Valve,” IEEE Trans. Intell. Transp. Syst., vol. 16, no. 5, pp. 2501–2510, 2015.

J. Xue, X. Jiao, and Z. Sun, “ESO-Based Double Closed-loop Servo Control for Automobile Electronic Throttle,” IFAC-PapersOnLine, vol. 51, no. 31, pp. 979–983, 2018.
